MISPC1800 PLUS(1-5KW)
The MPPT photovoltaic control inverter includes a pure sine wave inverter; Configurable input voltage range for household appliances (90-280VAC) and personal computers (170-280VAC) via LCD Settings; Solar charging and grid charging can be set through the LCD screen.
Category:INVERTER
Category:OFF Grid inverter
Contact Us
-
Product Description
-
Parameter
-
Product features:
· Pure sine wave output, can meet all types of load use
· Low no-load loss, high inverter efficiency, energy saving and environmental protection
· With multi-mode setting function, you can select off-grid and off-grid working mode through LCD screen
· With a wide range of mains input voltage, can be selected by LCD, to meet the needs of different equipment
· You can set the charging current and voltage on the LCD screen to meet different types of batteries
· With battery overdischarge, overload protection, overtemperature protection, short circuit protection and other protection functions
· With automatic frequency detection function, adapt to different power grid environment
· The parallel board can be added, three parallel machines can be expanded or three-phase input and output can be combined (optional)
· WIFI intelligent monitoring function, support mobile APP to view various data (optional)
-
model
MITPC1800-**** Plus
Rated battery voltage
24VDC
48VDC
Inverter output
power rating
2000W
3000W
3000W
4000W
5000W
5500W
Wave surge power
4000W
6000W
6000W
8000W
10000W
11000W
wave form
pure sine wave
AC voltage regulation (battery mode)
220VAC~240VAC (setup)
current
8.7A
13A
17.4A
21.7A
23.9A
Inverter efficiency (peak value)
93%
change-over time
10ms(UPS、VDE4105) 20ms( APL)
AC input
voltage
230VAC
The voltage range can be selected
170~280VAC(UPS), 90~280VAC(APL), 184~253VAC(VDE4105)
frequency range
50Hz / 60Hz (automatic detection)
Cell
cell voltage
24VDC
48VDC
floating charge voltage
27.4VDC
54.8VDC
Overcharge protection
30VDC
60VDC
PV Charger & power grid charger
Maximum PV array open-circuit voltage
145VDC
Photovoltaic Array, MPPT, voltage range
30~130VDC
64~130VDC
Standby loss
2W
Maximum photovoltaic array power
2000W
4000W
Maximum PV charging current
80A
Maximum conversion efficiency
98%
Max. AC charging current
60A
Maximum combined charging current
140A
specifications
Machine size (W * H * D)
272*355*100 mm
297.5*468*125mm
net weight (KG)
7.4
10
Package size (W * H * D)
570*405*246mm
610*405*241mm
rough weight (KG)
10
12.6
else
humidity
5% to 95% Relative humidity (non-condensing)
Machine running humidity
0° C ~55° C
Machine storage temperature
-15° C ~60° C
